As Patent Drawings Emerge, Dyson's Electric Car Takes Shape

Steph Willems
by Steph Willems
as patent drawings emerge dysons electric car takes shape

Dyson, the UK-based maker of innovative vacuums and fans, plans to launch an electric vehicle in about two years’ time — a promise backed up with over $2 billion in funding and the poaching of former Infiniti president Roland Krueger, who now heads the company’s automotive division.

The fledgling automaker doesn’t want to be an also-ran in the still-fledgling EV field. As the clock ticks closer to a real, physical car, new patent drawings reveal what it may look like.

The drawings, submitted in a late-2017 application but published only this week, appear to show a crossover. Surprised? Probably not. The drawings suggest the first Dyson vehicle will boast three rows of seating, a low center of gravity, and a truncated nose designed to present as little frontal area as possible. Its wheels, like those seen on the BMW i3, may be of the skinny, oversized variety. All of these measures aim to reduce aerodynamic drag, improving range.

The aluminum body Dyson previously copped to helps in that regard, too.

Still, the drawings are just that. In an email to employees obtained by Bloomberg, company founder James Dyson said the patent images are not a sure-fire glimpse of the final product. Rather, they represent “a glimpse of some of the inventive steps” the company is taking in its design process.

If you want to see an artist’s rendering based on the patent images, head on over to Autocar.

The secretive company plans to produce its vehicles in a Singapore assembly plant, though what type of battery will propel the unnamed vehicle remains a mystery. Dyson is very interested in solid-state batteries, said to harness significantly more energy than traditional lithium-ion packs, and has filed patent applications in the past for their design. Still, that technology — touted by the likes of Henrik Fisker — is in its infancy.

To date, no mass-produced electric car contains solid-state batteries.

[Images: Dyson]
